30° North
CALL FOR PRICE & AVAILABILITY
(251)980-2253
Features common to both Portable and Modular versions
1.5 HP totally enclosed fan cooled (TEFC) induction motor
1250 watts steady state power consumption
Current draw 6 amps (230VAC) or 12 amps (115VAC)
Power cord length: 3 metres (10 ft)
Plug type choices: US (NEMA 5-15), Australian (AS/NZS 3112), UK (BS 1363), Europe (CEE 7/7)
Integrated flexible impeller lift pump uses non-proprietary impeller
2 metre (6 ft) maximum lift above sea level
General Pump WMR 316 stainless steel high pressure triplex plungerpump
Integrated General Pump 316SS/ceramic relief valve to prevent overpressurisation
3 metre (10 ft) LDPE food grade product water hose, with 10 metre (33 ft) extension (8mm OD)
Sound levels – 62dB at 6 metres (20 ft) – see chart
Modular version specific features
No shell
PSU easy mounting kit: fibreglass reinforced nylon for high rigidity and tensile strength
RO easy mounting kit: fibreglass reinforced nylon for high rigidity and tensile strength
Plumbing installation kit included with purchase
Single 10″ x 2.5″ non-proprietary 5 micron prefilter to remove sediment with SS316 mounting bracket
0 – 150lph (40gph) product water flow meter, with SS316 mounting bracket
Valve/gauge control assembly at end of 5 metre (16 ft) high pressure hose for remote mounting
5 metre (16 ft) intake hose (1/2″ ID)
6 metre (20 ft) brine waste discharge hose (10mm OD)
PSU weight: 23kg (51lb)
PSU Dimensions : 470 x 270 x 240mm (18.5 x 10.7 x 9.5″)
Related RO weight
Related RO dimensions (in mounting brackets)High Output : 1,170 x 220 x 120mm (46.0 x 8.7 x 4.7″)Compact : 670 x 220 x 120mm (26.4 x 8.7 x 4.7″)Economy : 1,170 x 220 x 120mm (46.0 x 8.7 x 4.7″)
1 x 40″ RO Membranes
Our most common configuration with the AC system due to having the highest output and best overall value. Twice the output of the other options.
